Products
Max paper size: 800 x 620 mm
Min paper size: 340 x280 mm
Max cutting size: 770 x 600 mm
Die frame inner size: 820 x 628 mm
Cutting plate size: 826 x 628 mm
Min gripper edge size: 7 mm
Cutting precision: ≤±0.1 mm
Max cutting pressure: 200 T
Max cutting speed: 7000 S/H
Pre-stacking height: 1150 mm
Delivery stack height: 1000 mm
Application:
Card board: 0.1～2 mm
Corrugated paper: ＜4 mm
Main motor power: 11KW
Total power: 16.25 KW
Dimension : 5150(+1360) x 1900(+1680) x 1880 mm
Weight: 10 T
